A3DMarkupDatumData

Detailed Description

struct A3DMarkupDatumData

Markup datum.

This structure stored the definition of markups datum identifier and markups datum target according the several options ../../_images/pmi_datum.png

Public Members

A3DUTF8Char *m_pcUpText: Up text.

A3DUTF8Char *m_pcDownText: Down text.

A3DBool m_bTarget: Option: Is target?

A3DBool m_bDiameter: Option: Is diameter?

A3DBool m_bIndividual: Option: Is individual?

A3DMDTextProperties *m_pTextProperties

Pointer to the text properties.

See also

A3DMDTextPropertiesGet

A3DUTF8Char *m_pcAboveText

Above text in RTF format.

See RTF parsing.

Version: 12.2

A3DUTF8Char *m_pcBelowText

Below text in RTF format.

See RTF parsing.

Version: 12.2

A3DUTF8Char *m_pcBeforeText

Before text in RTF format.

See RTF parsing.

Version: 12.2

A3DUTF8Char *m_pcAfterText

After text in RTF format.

See RTF parsing.

Version: 12.2
