A3DMarkupLineWeldingData

Fields

`EA3DMDLineWeldingType`	`m_eArrowSideType`
`EA3DMDLineWeldingSupplSymbolType`	`m_eArrowSideSupplType`
`A3DUTF8Char` *	`m_pcArrowSideValue`
`A3DUTF8Char` *	`m_pcArrowSideLongitudinalValue`
`A3DUTF8Char` *	`m_pcArrowSideStaggeredValue`
`EA3DMDLineWeldingFinishSymbol`	`m_eArrowSideFinishSymbol`
`A3DUTF8Char` *	`m_pcArrowSideAngle`
`A3DUTF8Char` *	`m_pcArrowSideNumRootDepth`
`A3DUTF8Char` *	`m_pcArrowSideSize`
`A3DUTF8Char` *	`m_pcArrowSidePitch`
`EA3DMDLineWeldingType`	`m_eOtherSideType`
`EA3DMDLineWeldingSupplSymbolType`	`m_eOtherSideSupplType`
`A3DUTF8Char` *	`m_pcOtherSideValue`
`A3DUTF8Char` *	`m_pcOtherSideLongitudinalValue`
`A3DUTF8Char` *	`m_pcOtherSideStaggeredValue`
`EA3DMDLineWeldingFinishSymbol`	`m_eOtherSideFinishSymbol`
`A3DUTF8Char` *	`m_pcOtherSideAngle`
`A3DUTF8Char` *	`m_pcOtherSideNumRootDepth`
`A3DUTF8Char` *	`m_pcOtherSideSize`
`A3DUTF8Char` *	`m_pcOtherSidePitch`
`A3DUTF8Char` *	`m_pcStandard`
`A3DUns32`	`m_uiNumberOfProcesses`
`A3DUns32`	`m_uiNumberOfCoordinate`
`A3DUTF8Char` **	`m_ppcProcess`
`A3DUns32`	`m_uiCoordinateEntitiesNotesSize`
`A3DUTF8Char` **	`m_ppCoordinateEntitiesNotes`
`A3DUns32`	`m_uiProcessNotesSize`
`A3DUTF8Char` **	`m_ppProcessNotes`
`A3DMDTextProperties` *	`m_pTextProperties`

Detailed Description

struct A3DMarkupLineWeldingData

Markup line welding symbol.

../../_images/pmi_welding_symbol.png

Version: 4.0

Public Members

EA3DMDLineWeldingType m_eArrowSideType: Undocumented.

EA3DMDLineWeldingSupplSymbolType m_eArrowSideSupplType: Undocumented.

A3DUTF8Char *m_pcArrowSideValue: Undocumented.

A3DUTF8Char *m_pcArrowSideLongitudinalValue: Undocumented.

A3DUTF8Char *m_pcArrowSideStaggeredValue: Undocumented.

EA3DMDLineWeldingFinishSymbol m_eArrowSideFinishSymbol: Undocumented.

A3DUTF8Char *m_pcArrowSideAngle: Groove Angle or Countersink Angle, degree symbol to add.

A3DUTF8Char *m_pcArrowSideNumRootDepth: Undocumented.

A3DUTF8Char *m_pcArrowSideSize: Undocumented.

A3DUTF8Char *m_pcArrowSidePitch: Undocumented.

EA3DMDLineWeldingType m_eOtherSideType: Undocumented.

EA3DMDLineWeldingSupplSymbolType m_eOtherSideSupplType: Undocumented.

A3DUTF8Char *m_pcOtherSideValue: Undocumented.

A3DUTF8Char *m_pcOtherSideLongitudinalValue: Undocumented.

A3DUTF8Char *m_pcOtherSideStaggeredValue: Undocumented.

EA3DMDLineWeldingFinishSymbol m_eOtherSideFinishSymbol: Undocumented.

A3DUTF8Char *m_pcOtherSideAngle: Undocumented.

A3DUTF8Char *m_pcOtherSideNumRootDepth: Undocumented.

A3DUTF8Char *m_pcOtherSideSize: Undocumented.

A3DUTF8Char *m_pcOtherSidePitch: Undocumented.

A3DUTF8Char *m_pcStandard: Undocumented.

A3DUns32 m_uiNumberOfProcesses: Undocumented.

A3DUns32 m_uiNumberOfCoordinate: Undocumented.

A3DUTF8Char **m_ppcProcess: Undocumented.

A3DUns32 m_uiCoordinateEntitiesNotesSize: Number of note texts.

A3DUTF8Char **m_ppCoordinateEntitiesNotes: Array of note texts.

A3DUns32 m_uiProcessNotesSize: Number of process texts.

A3DUTF8Char **m_ppProcessNotes: Array of process texts.

A3DMDTextProperties *m_pTextProperties

Pointer to the text properties.

See also

A3DMDTextPropertiesGet
